Asus RS500A-E12-RS4U 90SF02J1-M000R0

0 %

(0 hodnocení)

Koupit za 71 213 Kč

Od nejoblíbenějších
Od nejlevnějších
Od nejdražších

95 %

Asus RS500A-E12-RS4U 90SF02J1-M000R0

Doprava: 79 Kč Skladem

71 213 Kč Koupit za 71 213 Kč

100 %

ASUS 1U server SP5 24x DDR5 4800 4x 3.5 NVMe/SATA, 3x PCIe5.0, 2x i350 1Gb, 2x800Wt, 90SF02J1-M000R0

Doprava: zdarma Skladem

68 939 Kč Koupit za 68 939 Kč

92 %

Asus RS500A-E12-RS4U/800W/4NVMe/OCP 90SF02J1-M000R0

Doprava: zdarma Skladem

67 409 Kč Koupit za 67 409 Kč

87 %

ASUS RS500A-E12-RS4U/800W/4NVMe/OCP - 90SF02J1-M000R0

Doprava: zdarma Skladem

64 287 Kč Koupit za 64 287 Kč

88 %

Asus RS500A-E12-RS4U 90SF02J1-M000R0

Doprava: zdarma Skladem

62 350 Kč Koupit za 62 350 Kč

Zobrazit další nabídky

Popis

CPU

Platform

CPU

Scoket

CPU #

U

Max

CPU TDP

Chipset

Memory

Type

Memory

#

Storage

#

Storage

Bay

Storage

Type

NVMe grade

(option)

Storage

Hotswap

SAS

Controller

M.2

Other

Storage

ODD

O/B NIC

GPU

Sport

PCIe

#

PCIe slots

OCP

PSU

#

Railkit

PSU

Type

Heatsink

Type

Depth

(mm)

EPYC

Genoa

LGA6096

1

1U

240W

SOC

DDR5 4800

12

4

3.5"

SATA/SAS*/4xNVMe

-

Y

Option

2

0

0

Intel i350 1Gb x2

-

3

1 x PCIe x16 slot (Gen5 x16 link, FH, HL) 1 x PCIe x16 slot (Gen5 x16 link, LP, HL)

1 x PCIe x16 slot (Gen5 x8 link, LP, HL)

3.0X1

1+1

1000mm

Friction

800W 80+ Titanium

1U EVAC HS

842.5 x 449 X 43.85

-

Processor / System Bus

1 x Socket SP5 (LGA 6096)

AMD EPYC™ 9004 Series Processors (up to 400W)

-

Memory

24 x DIMM slots

DDR5 4800/4400 RDIMM/ 3DS RDIMM

Maximum 6144GB

*2DPC support depends on AMD schedule

* Refer to support page for more information

-

Expansion Slots

Up to 3 PCIe Gen5 slots + 1 OCP3.0

1 x PCIe x16 slot (Gen5 x16 link, FH, HL)

1 x PCIe x16 slot (Gen5 x16 link, LP, HL)

1 x PCIe x16 slot (Gen5 x8 link, LP, HL)

1 x OCP3.0 socket (Gen5 x16 link)

-

Storage

Storage Controller :

CPU Integrated

Optional kits Controller :

ASUS PIKE II 3008-8i 8-port SAS 12G HBA card

-

Drive Bays

Front bays:

4 x 2.5” Hot-swap Storage Bays

4 x SATA/SAS/NVME

*SAS support only from optional SAS

HBA/RAID card

2 x M.2 connectors

-

Networking

1 x Dual Port Intel I350-AM2 GbE LAN Controller

1 x Management Port

-

Graphic

Up to 2 single-slot GPU cards

-

Front I/O Ports

2 x USB 3.2 Gen1 ports

1 x VGA port

-

Rear I/O Ports

2 x USB 3.2 Gen1 ports

1 x VGA port

1 x Management port

2 x 1GbE LAN ports

-

Switch/LED

Front:

1 x Power Button/LED

1 x Location Button/LED

1 x Message LED

1 x HDD LED

4 x LAN LED (1-2 for on-board LAN, 3-4 for OCP LAN)

Rear:

1 x Port80 LED (Q-Code)

1 x Power Button/LED

1 x Location Button/LED

1 x Message LED

-

OS Support

Please find the latest OS support from https://servers.asus.com/support/os

-

Management Solution

ASUS Control Center

ASUS ASMB11-iKVM (on-board)

-

Regulatory Compliance

BSMI, CB, CE, RCM, FCC(Class A)

-

Dimensions

842.5mm x 449mm x 43.85mm (1U)

33.17" x 17.68" x 1.73"

-

Form Factor

1U

-

Weight

(approximate)

Net Weight: 13.15 kg

Gross Weight: 18.15 kg

-

Power Supply

1+1 Redundant 1600W 80 PLUS Titanium

Power Supply

1+1 Redundant 1200W/800W 80 PLUS Platinum

Power Supply

-

Environment

Operating temperature: 10°C – 35°C

Non operating temperature: -40°C – 70°C

Non operating humidity: 20% – 90% (Non condensing)

Note

Operating Temperature based on configurations

- Products certified by the Federal Communications Commission and Industry Canada will be distributed in the United States and Canada. Please visit the ASUS USA and ASUS Canada websites for information about locally available products.

- All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.

- Specifications and features vary by model, and all images are illustrative. Please refer to specification pages for full details.

- PCB color and bundled software versions are subject to change without notice.

- Brand and product names mentioned are trademarks of their respective companies.

- The terms HDMI and HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

- The information contained is general testing result for reference. Please consult local sales representative for more information on specific supported CPU list on each system.

- * Optional means “built for order”.

EAN: 4711387030448
