Popis
- Support VGA, HDMI full HD output simultaneously;
- Support ONVIF; access third party;
- Support AHD, TVI ,CVI,CVBS,IPHD video input;
- Support Web, CMS, center platform management software XMEYE, provide SDK development;
- Support multiple cloud technology, network penetration, alarm information pushed to your phone and other functions;
- Support various mobile monitoring (iPhone, Android);
- Remote Access, With DNS (ARSP),easy to monitor remotely;
Specification:
Model
A6916S-5MP
System
Main processor
Technical grade embedded microprocessor NT98336
Operating system
Embedded LINUX operating system
System resource
Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up.
Interface
Operation interface
16bit real color GUI interface support mouse operation
Display screen
1/4/8 screen (take analog channel as an example, other is base on the selected channel mode)
??
Video standard
PAL/NTSC
Image encode
H.265(High Profile)
Monitor quality
4K
Playback quality
4*8M(4FPS)/16*5M(6FPS)(6IN1)
Decode capability
16*4K @4fps(6 in 1)/16*5M@6fps(6 in 1)/
16*4M@9fps(6 in 1)/16*3M@10fps(6 in 1)/16*1080P@16fps(6 in 1)
Encode capability
16*4K @4fps(6 in 1)/16*5M@6fps(6 in 1)/
16*4M@9fps(6 in 1)/16*3M@10fps(6 in 1)/16*1080P@16fps(6 in 1)
Multi-mode video input
AHD: 16*4K/16*5M
HVR:16*8M(AHD)+16*8M(IP)
NVR: 16*4K/16*5M
Motion detection
Each channel can set 192(16*12)detection area;can set multi-level of flexibility (for local analog channel only)
Audio
Audio compression
G711A
Bidirectional talk
support
Record and playback
Record mode
manual>alarm>motion detection>timing
Local playback
1-9ch playback synchronously (take local analog input for example, other is depended on the selected channel mode)
Video search
time?date?event?channel search
Storage and back up
Space occupation
Video:CIF 4~5G/day*channel, D1 16~20G/day*channel;
audio:691.2M/day*channel
Video storage
Local HDD ?Network
Back up mode
Network backup?USB portable HDD?USB imprint?SATA imprint
Interface
Video input
16CH BNC(1.0Vp-p,75?)
Video output
1CH VGA,1CH HDMI
Audio input
2CH RCA
Audio output
1CH RCA(200-3000mV,5K?)
Alarm input
No
Alarm output
No
Network port
RJ45 10M/100M/1000M self-adaptive Ethernet port
PTZ control
1 RS485;support multi kinds of PTZ protocol
USB port
2*USB2.0
HDD port
1SATA ports(each max to 8TB)
Wireless port
3G?WIFI(extension via USB port)
other
Power
12V/4A
Consumption
